Features:
1. High conversion efficiency (energy efficiency VI)
2. Protection: OCP, OVP, OTP
3. EMC regulatory certification
4. RoHS&REACH
5. Support customized power supply
Output:
| Voltage |
8.0-17.0V |
17.1-27.0V |
27.1-40.0V |
40.1-55.0V |
| Current |
0.01-4.25A |
0.01-2.13A |
0.01-1.41A |
0.01-1.06A |
| Power max |
51W |
51W |
51W |
51W |
Safety approvals
GB4943.1-2011, GB8898-2011,GB4706.1-2005, EN62368, IEC60950, EN61558,K60950,J60950,J60065,J61558,UL62368,UL60950,AS/NZS61558,AS/NZS60950, AS/NZS60065,IS13252
EMC
GB17625.1-2012,GB/T9254- 2008,GB/T13837-2012,GB/T17625.1-2007,GB4343.1-2018,EN55032, EN55014, EN55024,EN61000,KN-32/35,FCC Part15
DC connector
