Features:
1. High conversion efficiency (energy efficiency VI)
2. Protection: OCP, OVP, OTP
3. EMC regulatory certification
4. RoHS&REACH
5. Support customized power supply
Output:
| Voltage |
8-16.9V |
17.0-23.0V |
23.1-35.0V |
35.1-42.0V |
42.1-55.0V |
| Current |
0.01-5.0A |
0.01-3.64A |
0.01-2.75A |
0.01-1.88A |
0.01-1.56A |
| Power max |
60W |
62W |
66W |
66W |
66W |
Safety approvals
GB4943.1-2011,GB8898-2011,GB4706.1-2005, EN62368,IEC60950, EN61558,K60950,J60950,J61558,UL62368,AS/NZS61558,AS/NZS60950,IS13252
EMC
GB17625.1-2012, GB/T9254-2008, GB/T13837-2012,GB/T17625.1-2007, GB4343.1-2018,EN55032,EN55014,EN55024,EN61000,EN55035,KN-32/35,FCC Part 15, AS/-ZS CISPR 32, AS/NZS CISPR 14
DC connector
